Thermo Partisol PM Samplers

Thermo Partisol PM Samplers - Single and Multi Filter Versions available

2000i Single Filter

Meet regulatory monitoring requirements for PM-2.5, PM-10 and other particulate sampling methods with the Thermo Scientific™ Partisol 2000i Air Sampler, a federal reference method ambient sampler. Featuring enhanced communication capabilities and and long-term unattended operation, the 2000i provides reliable and quiet operation, low maintenance requirements and a single-action filter exchange mechanism for added convenience.

2025i Multi Filter (Auto)

Store 16 filter cassettes, allowing for two weeks of unattended daily-sampling of particulate matter with the Thermo Scientific™ Partisol™ 2025i Sequential Air Sampler. Developed on the renowned iSeries software platform design, this sampler features USB ports for improved data downloads, and exchanged 47mm diameter sample filters automatically, which can be preset to a user-defined time interval. * Specification shown for this model

2025i Dichotomous (Single or Multi Auto)

Simultaneously collect high-quality samples of fine and coarse ambient particulate matter (PM) with the thermo Scientific™ Partisol™ 2025i-D Dichotomous Air Sampler. Developed on the renowned iSeries software platform design, this sampler features USB ports for improved data downloads, and exchanged 47mm diameter sample filters automatically, which can be preset to a user-defined time interval. This is a federal-equivalent method, ambient sampler that simultaneously collects high quality samples of fine and coarse ambient particulate matter (PM).

Product Size -
Height (English) 26.3 in. (Overall)/31 in. (Top Cover)/27.1 in. (Stand)
Height (Metric) 67.3cm (Overall)/78.8cm (Top Cover)/68.8cm (Stand)
Weight (English) 101 lb.
Weight (Metric) 46kg
Width (English) 25.2/35.3/30.8/106.7 in.
Width (Metric) 64cm (Overall)/89.5cm (Inlet Connector)/78.2cm (Stand)/106.7cm (Footprint)
Description Air Sampler
Filter Holders and Media Accommodates 47mm filter in the single-flow and dual-flow configurations (for U.S. EPA PM-2.5 and PM-Coarse sampling); PTFE 2µm pore size membrane filter (regulation required) (for U.S. EPA PM-10 reference sampling: Pallflex TX-40, quartz filter and PTFE
Internal Data Storage 86 days of Interval data (stored every 5 minutes), 32 filter data records, and input data (30 minute default)
Safety and Electrical Designations CE: EN550011 Group 1, Class B (Emissions); EN55082-1 (Immunity); EN61010-1 (Safety)ETL: UL and CSA Equivalent approval
Sample Flow Control and Reporting Activol flow control system using mass flow controller. Controls at rates ranging from 10 to 19 volumetric L/min. The sampler displays the current volumetric flow rate (L/min.).
Temperature (English) Operating -14° to +122°F
Temperature (Metric) Operating -40° to +50°C
Calibration Direct software support for single-point and multi-point audit/calibrations of the volumetric flow
Depth (English) 15.8 in.
Depth (Metric) 40.2cm
Input/Output Keypad/display for data retrieval and user programming, RS232/RS485 interface, Wind vane/anemometer connection with 24Vdc power output and 2 0-5 Vdc inputs for wind speed and direction; Dual USB ports for easy data download to universal flash drives; Optional kit available to configure the sampler for digital and analog I/O to enable connection to other devices
Item Description Air Sampler
Power Consumption 3A (at 120VAC); 1.5A (at 240VAC)
Regulatory Compliance U.S. EPA PM-2.5 Reference Method: RFPS-0498-118U.S. EPA PM-10 Reference Method: RFPS-1298-127U.S. EPA PM-Coarse Reference Method: RFPS-0509-176
I want to measure Particulate Matter [PM1],Particulate Matter [PM10],Particulate Matter [PM2.5],Particulate Matter Total [TSP]
Products Particle Samplers
Applications Outdoor Air Quality
