2BTech POM

2BTech POM

The Personal Ozone Monitor (POM) has dimensions of 4 x 3 x 1.5 inches and weighs only 0.75 lb (340 g). It has a built in GPS so that ozone measurements may be logged continuously along with geographic location. By folding the optical path in the shape of a "U", it was possible to achieve the same path length in the POM as in much larger models such as the 202, 205 and 106-L and thus have similar precision and accuracy (~2 ppb).

Measurement Principle UV Absorption at 254 nm
Federal Equivalent Method (FEM) Yes, EQOA–0815–227
Linear Dynamic Range 0 ppb to 10 ppm
Resolution 0.1 ppb
Precision (1σ rms noise) Greater of 1.5 ppb or 2% of reading
Accuracy Greater of 1.5 ppb or 2% of reading
Limit of Detection (2σ) 3 ppb
NIST-Traceable Calibration Yes
Measurement Intervals Measurement mode: 10 s (Fast mode: 2 s)
Flow Rate (nominal) ~0.8 Liter/min
Flow Rate Requirement >0.5 L/min
Baseline Drift < 2 ppb/day
<5 ppb/year
Sensitivity Drift < 1%/day
<3%/year
Measurement Time, Frequency 10 s, 0.1 Hz (Fast mode: 2 s, 0.5 Hz)
Response Time, 100% of Step Change For 10-s output: 20 s, 2 points (For 2-s output: 4 s, 2 points)
Averaging Times 1 min, 5 min, 1 hr
Data Storage 8,192 lines (2-s fast mode ~4.6 hr; 10-s meas. mode ~1 day; 1-min avg ~6 days; 5-min avg ~1 mo; 1-hr avg ~1 yr)
Ozone Units ppb
Pressure Units torr
Temperature Units K
T and P Corrected Yes
Operating Temperature Range 0 to 50 °C
Operating Altitude Range ~0-13.5 km (150-1,013 mbar) [modifications for higher altitudes available as an option]
Power Requirement;
Supplied by battery or 110/220 VAC Power Pack
7-24 V dc, nominally 250 mA at 12 V, 3.0 watt
External Battery 7.4 Volt, 1.6 amp hour, Lithium Ion Battery, 5-8 hr
Size 4.0 x 3.0 x 1.5 inches (10.2 x 7.6 x 3.8 cm)
Weight 0.75 lb. (0.34 kg)
Data Transfer Baud Rate 19200
DewLine™ Yes
GPS Yes
Sampling Probe Available as an option
I want to measure Ozone [O3]
Products Gas Monitors,Portable Monitors,Personal Monitors,Portable Monitors
Applications Indoor Air Quality,Occupational Exposure,Outdoor Air Quality,Personal Exposure,
